Introduction

In the field of electrical engineering, a series LCR circuit is a fundamental circuit consisting of an inductor (L), a capacitor (C), and a resistor (R) connected in series. The behavior of this circuit is crucial in understanding various electrical phenomena, including resonance. In this article, we will delve into the concept of resonant frequency and quality factor in a series LCR circuit.

Resonant Frequency

The resonant frequency of a series LCR circuit is the frequency at which the circuit's impedance is at its maximum, resulting in maximum current and minimum voltage across the circuit. Mathematically, the resonant frequency (f0) is given by:

f0 = 1 / (2π√(LC))

where L is the inductance and C is the capacitance.

Quality Factor

The quality factor (Q) of a series LCR circuit is a measure of its ability to store energy. It is defined as the ratio of the resonant frequency to the bandwidth of the circuit. The bandwidth is the range of frequencies over which the circuit's impedance is within 3 dB of its maximum value. Mathematically, the quality factor (Q) is given by:

Q = f0 / (Δf)

where Δf is the bandwidth.

Half Power Points

In a series LCR circuit, the half power points are the frequencies at which the circuit's power is half of its maximum value. These frequencies are typically denoted as f1 and f2. The bandwidth (Δf) is given by:

Δf = f2 - f1

Given Data

In this problem, we are given the following data:

Resonant frequency (f0) = 500 Hz
Half power points (f1 and f2) = 475 Hz and 525 Hz, respectively

Calculating the Quality Factor

To calculate the quality factor (Q), we need to first calculate the bandwidth (Δf). We can do this by finding the difference between the two half power points:

Δf = f2 - f1 = 525 Hz - 475 Hz = 50 Hz

Now, we can calculate the quality factor (Q) using the formula:

Q = f0 / (Δf) = 500 Hz / 50 Hz = 10

Conclusion

In this article, we have discussed the concept of resonant frequency and quality factor in a series LCR circuit. We have also provided a step-by-step solution to calculate the quality factor (Q) given the resonant frequency and half power points. The quality factor (Q) is a crucial parameter in understanding the behavior of a series LCR circuit, and its value can be calculated using the formula Q = f0 / (Δf).

References

[1] "Electrical Circuits" by James W. Nilsson and Susan A. Riedel
[2] "The Art of Electronics" by Paul Horowitz and Winfield Hill
