Introduction

In the field of electrical engineering, understanding the behavior of transmission lines is crucial for designing and optimizing communication systems. The attenuation and phase constant of a transmission line are two fundamental parameters that determine its performance. In this article, we will delve into the analysis of a transmission line with an attenuation of 10 dB/m and a phase constant of 50 radians/m at 2 GHz.

Complex Propagation Constant

The complex propagation constant is a measure of the attenuation and phase shift of a transmission line. It is represented by the symbol γ and is given by the equation:

γ = α + jβ

where α is the attenuation constant and β is the phase constant.

Attenuation Constant

The attenuation constant (α) is a measure of the rate at which the signal is attenuated as it travels through the transmission line. It is typically measured in units of nepers per meter (Np/m) or decibels per meter (dB/m). In this case, the attenuation constant is given as 10 dB/m.

Phase Constant

The phase constant (β) is a measure of the rate at which the signal is phase-shifted as it travels through the transmission line. It is typically measured in units of radians per meter (rad/m). In this case, the phase constant is given as 50 radians/m.

Complex Propagation Constant

To find the complex propagation constant, we need to combine the attenuation and phase constants. Since the attenuation constant is given in decibels per meter (dB/m), we need to convert it to nepers per meter (Np/m) using the following equation:

α (Np/m) = α (dB/m) / 8.686

Substituting the given value, we get:

α (Np/m) = 10 dB/m / 8.686 ≈ 1.15 Np/m

Now, we can find the complex propagation constant (γ) by combining the attenuation and phase constants:

γ = α + jβ = 1.15 Np/m + j50 rad/m

Capacitance and Conductive Loss

The capacitance of the line is given as 100 pF/m, and the conductive loss is zero (i.e., G = 0). We can use the following equation to find the attenuation constant (α) in terms of the capacitance and conductive loss:

α = G + jωC

where ω is the angular frequency (2πf) and C is the capacitance per unit length.

Substituting the given values, we get:

α = 0 + j2π(2 GHz)(100 pF/m) = j2π(2 GHz)(100 pF/m) ≈ j125.66 rad/m

Comparing this value with the previously calculated value of α (1.15 Np/m), we can see that there is a discrepancy. This is because the conductive loss is zero, and the capacitance is not taken into account in the previous calculation.

Conclusion

In conclusion, we have analyzed a transmission line with an attenuation of 10 dB/m and a phase constant of 50 radians/m at 2 GHz. We have found the complex propagation constant (γ) by combining the attenuation and phase constants. We have also discussed the capacitance and conductive loss of the line and their effect on the attenuation constant (α).

References

[1] R. E. Collin, Foundations for Microwave Engineering, 2nd ed., McGraw-Hill, 2001.
[2] D. M. Pozar, Microwave Engineering, 3rd ed., Wiley, 2005.
[3] J. D. Kraus, Antennas, 2nd ed., McGraw-Hill, 1988.

Keywords

Transmission line
Attenuation constant
Phase constant
Complex propagation constant
Capacitance
Conductive loss
Microwave engineering
Antennas
