Manufacturing Voltage Stabilizers with Digital Control Using Atmega 8535: A Comprehensive Study

Introduction

Voltage fluctuations are a common problem in electricity sources, which can damage electronic equipment and lead to costly repairs. In this study, we designed a voltage stabilizer with digital control using an ATMEGA 8535 microcontroller to overcome this problem. This tool is an efficient solution that can maintain a stable voltage level, extending the life of electronic devices and reducing maintenance costs.

Design and Components

The voltage stabilizer consists of several main components, including a microcontroller circuit that functions to process input and output, the power supply circuit to provide a voltage source to the microcontroller, the LCD screen for the information display, and the L293D IC that functions as a motor driver. The voltage sensor circuit becomes a crucial component in this system, which is tasked with providing feedback to the control system when the output voltage of the Toroid transformer does not reach 220V.

How it Works

When the sensor detects instability in the output voltage, the microcontroller processes the data and sends commands to the motor driver to turn the lever connected to the transformer. This process continues until the resulting voltage is stable again at the desired value. The system is also equipped with a safety mechanism that automatically disconnects the load if the voltage output exceeds the threshold limit of 230V, protecting electronic equipment from damage due to excessive voltage.

Microcontroller Selection

The Microcontroller of the Atmega 8535 was chosen for this application due to its ability to process data quickly and the availability of input and output pins sufficient to connect various components. Additionally, ease of programming and flexibility in controlling control logic make it the ideal choice for this application.

Power Supply Design

The special designed power supply series is also very important, as it is the main source of voltage for the whole system. The stability of this power supply will directly affect the performance of the tool. Therefore, special attention must be given in the design of the power supply so that it can function properly in various load conditions.

Voltage Sensor

The voltage sensor used in this system functions as the main supervisor. By using a high-quality sensor, the accuracy of voltage measurement can be maintained, so that the response to changes in voltage can be done quickly. This ensures that the stabilizer can function optimally and maintain voltage at a safe level for connected electronic devices.

Implementation and Benefits

Through the implementation of this system, it is expected to make a significant contribution in maintaining the stability of the voltage, which in turn will extend the life of electronic devices and reduce maintenance costs due to damage. This stabilizer is very suitable for use in various environments, ranging from households to industry, where stability of voltage is the key to operational success.

Conclusion

In conclusion, this study shows that a combination of microcontroller technology and a good circuit design can produce efficient and reliable tools in dealing with electric voltage problems. The voltage stabilizer with digital control using Atmega 8535 is a valuable contribution to the field of electrical engineering, providing a solution to the problem of voltage fluctuations and extending the life of electronic devices.

Future Work

Future work can focus on improving the design of the power supply and the voltage sensor to make the system even more efficient and reliable. Additionally, the system can be modified to include additional features, such as automatic voltage regulation and fault detection.

References

[1] ATMEGA 8535 Microcontroller Datasheet
[2] L293D IC Datasheet
[3] Toroid Transformer Datasheet
[4] Voltage Sensor Datasheet

Appendix

The appendix includes the detailed circuit diagram and the code for the microcontroller. The circuit diagram shows the connection of the various components, including the microcontroller, power supply, LCD screen, and motor driver. The code for the microcontroller is written in C and includes the program for the voltage sensor, motor driver, and LCD screen.

Circuit Diagram

The circuit diagram is shown below:

[Insert circuit diagram]

Code

The code for the microcontroller is shown below:

#include <avr/io.h>
#include <avr/interrupt.h>

#define F_CPU 16000000UL

int main() {
    // Initialize the microcontroller
    DDRB = 0xFF;
    DDRD = 0xFF;

    // Initialize the voltage sensor
    ADCSRA = (1 << ADEN) | (1 << ADIE) | (1 << ADATE);
    ADMUX = (1 << REFS0) | (1 << MUX0) | (1 << MUX1);
    ADCSRB = (1 << ADTS2) | (1 << ADTS0);

    // Initialize the motor driver
    PORTB = 0xFF;
    PORTD = 0xFF;

    // Initialize the LCD screen
    LCD_init();

    while (1) {
        // Read the voltage sensor
        ADCSRA |= (1 << ADSC);
        while (ADCSRA & (1 << ADSC));
        int voltage = ADC;

        // Check if the voltage is within the desired range
        if (voltage < 220) {
            // Turn the motor driver on
            PORTB = 0xFF;
            PORTD = 0xFF;
        } else {
            // Turn the motor driver off
            PORTB = 0x00;
            PORTD = 0x00;
        }

        // Display the voltage on the LCD screen
        LCD_print(voltage);
    }

    return 0;
}

Note: The code is written in C and is specific to the ATMEGA 8535 microcontroller. The code includes the program for the voltage sensor, motor driver, and LCD screen.
