Comparison of Bored Pile Foundation Carrying Capacity Analysis in Sta 43+030 at Point B Using the Element Method to and Analytical Methods (Case Study of the Sei Wampu Bridge Development Project)

Introduction

The foundation is a crucial component of a building structure, serving as a medium to transfer loads from the structure above it to the ground. Foundations can be broadly categorized into two types: shallow foundations and deep foundations. The selection of the foundation type is heavily dependent on the load-bearing capacity and the condition of the land at the project site. For light loads and good soil conditions, shallow foundations are typically used, whereas for heavy loads, deep foundations are the preferred choice.

Importance of Foundation Analysis in Bridge Construction

In the Sei Wampu Bridge construction project in Stabat, the analysis of the carrying capacity of the axial foundation of the drill pile was carried out using Standard Penetration Test (SPT) data. The methods employed in this calculation include the Reese & Wright method, testing pile driving analyzer (PDA), and analysis using the element method (meh). Additionally, the analysis of lateral carrying capacity was conducted using the Brooms method, which incorporates calculations for decreased elastic piles, pole efficiency, and carrying capacity of pole groups.

Comparison of Carrying Capacity Analysis Results

The results of the calculation of the carrying capacity of the ultimate pole carried out at the Bore Hole I point, with a depth of 30.5 meters, showed a value of 593,468 tons based on SPT data. These results are consistent with the calculation using the Reese & Wright method, which also produced 593,468 tons. However, the analysis using PDA yielded a lower value, at 553.07 tons. On the other hand, the calculation using the element method showed a value of 593,112 tons.

Lateral Ultimate Carrying Capacity Analysis

The lateral ultimate carrying capacity obtained through the Brooms method showed results of 43,0251 tons analytically and 46.715 tons graphically. Furthermore, the single elastic decline produced was recorded at 1,0012 mm, while based on the poulus and davis methods, the decrease reached 16.84 mm. The decrease calculated by the element method was 2.15 mm.

Variations in Carrying Capacity and Decrease

From this analysis, it appears that there are variations in the carrying capacity and decrease resulting from various methods used. This variation can be attributed to several factors, including differences in the type of soil, depth under study, the method of implementing testing, safety factors applied, and differences in the parameters used in each calculation.

Importance of Choosing the Right Method

In-depth analysis of these results highlights the significance of selecting the right method in the calculation of the carrying capacity of the foundation. Differences in yields can have major implications for the design and safety of the structure, especially on large projects such as bridge construction. Therefore, a strong understanding of the condition of the soil and the right calculation method is necessary to achieve optimal results in the foundation design.

Accuracy of Results in Construction

The accuracy of the results of this calculation becomes very important in the world of construction. This is because the decision taken based on this analysis will affect the overall performance of the structure in the future. Therefore, a comprehensive study and comparison of various methods of analysis of the carrying capacity of the foundation is highly recommended to ensure the safety and efficiency of the structure that is built.

Conclusion

In conclusion, the analysis of the carrying capacity of the bored pile foundation in Sta 43+030 at point B using the element method to and analytical methods has shown variations in the carrying capacity and decrease resulting from various methods used. This highlights the importance of choosing the right method in the calculation of the carrying capacity of the foundation. A strong understanding of the condition of the soil and the right calculation method is necessary to achieve optimal results in the foundation design. Therefore, a comprehensive study and comparison of various methods of analysis of the carrying capacity of the foundation is highly recommended to ensure the safety and efficiency of the structure that is built.

Recommendations

Based on the findings of this study, the following recommendations are made:

Selection of the Right Method: The selection of the right method in the calculation of the carrying capacity of the foundation is crucial. A strong understanding of the condition of the soil and the right calculation method is necessary to achieve optimal results in the foundation design.
Comprehensive Study: A comprehensive study and comparison of various methods of analysis of the carrying capacity of the foundation is highly recommended to ensure the safety and efficiency of the structure that is built.
Accuracy of Results: The accuracy of the results of this calculation becomes very important in the world of construction. This is because the decision taken based on this analysis will affect the overall performance of the structure in the future.
Safety and Efficiency: The safety and efficiency of the structure that is built are highly dependent on the accuracy of the results of this calculation. Therefore, a comprehensive study and comparison of various methods of analysis of the carrying capacity of the foundation is highly recommended.
