Introduction

Passive Safety Systems in Vehicles The safety of passengers and vital parts of a vehicle is a top priority in the automotive industry. One of the key components that play a crucial role in reducing the severity of accidents is the crash box, a passive safety system designed to absorb the energy produced during collisions. In this study, we analyzed the effect of the tapered wall angle variation and the location of the trigger circles on a circular crash box against energy absorption and deformation patterns in the quasi-static loading simulation.

Background and Research Objectives The crash box is a critical component in vehicle safety, and its performance is influenced by various factors, including the tapered wall angle and the location of the trigger circles. The objective of this study was to investigate the effect of these variables on energy absorption and deformation patterns in the crash box using the Finite Element Method (FEM) software.

Methodology

Materials and Methods

Crash Box Design: The crash box was designed with a circular shape and a tapered wall angle of 1° and 5.7°.
Material: The crash box material used was aluminum 6061-T4.
Trigger Circles: The trigger circles were placed at points A, B, C, and D.
Quasi-Static Loading Simulation: The quasi-static loading simulation was conducted using FEM software to analyze the energy absorption and deformation patterns.

Variations Used in the Study

Tapered Wall Angle: The tapered wall angle was varied at 1° and 5.7°.
Location of Trigger Circles: The trigger circles were placed at points A, B, C, and D.

Results

Deformation Patterns

Axial Patterns with Mixed Mode: The deformation pattern formed was axial patterns with mixed mode (Concertina + Diamond).
Deformation at Tapering Corner: Deformation of this mixture mode occurs at the tapering corner of the crash box of 1° and 5.7°.

Energy Absorption

Highest Energy Absorption Ability: The crash box with a tapered angle (α) 5.7° shows the highest energy absorption ability, reaching 3124.0 joules.

Discussion

Energy Absorption in the Crash Box

Importance of Energy Absorption: Energy absorption in the crash box is very crucial to ensure the safety of passengers and the structural integrity of the vehicle.
Influence of Tapered Wall Angle: The variation of the tapered wall angle has the potential to influence the efficiency of energy absorption.

Deformation Patterns

Mixed Mode Deformation: The deformation pattern formed during the collision provides an important indication of the performance of the crash box.
Optimal Design for the Crash Box: The tapered angle of 5.7°, which shows the highest energy absorption, also provides insight into the optimal design for the crash box in the future.

Research Significance

Contribution to Vehicle Safety Technology: The results of this study not only provide a clear picture of how the variations of tire and trigger circles affect the performance of the crash box but also contribute to the development of vehicle safety technology.
Importance for Automotive Engineers: Knowledge of deformation patterns and energy absorption capabilities is very important for automotive engineers in designing safer and more efficient components.

Conclusion

Relationship between Variables: Overall, this study succeeded in showing the relationship between the corners of the tapered wall, the position of the circles trigger, and the absorption of energy in the crash box.
Future Research Directions: With a better understanding of these variables, the automotive industry can continue to innovate in creating a more effective safety system. In the future, further research can be done by testing other materials and additional design variations to achieve a higher level of safety.

References

[List of references cited in the study]
